NBN pit and pipe design for developments across Australia

Single and multi dwelling unit developments in any state or territory. Designs are prepared to NBN's current pit and conduit standard by an NBN accredited designer.

Get a quote See pricing
16273849510ConduitPitRoad crossingDRAWINGNBN pit and pipe layoutDEVELOPMENTSDU, 10 lotsSCALENTSSTATUSIllustrative
Illustrative layout of a 10 lot street. One pit serves five lots, and each lot has its own conduit from the pit.
NBN trained Pathway Designer and NBN trained Pit and Pipe Designer

NBN accredited designer. Michael Almond is NBN accredited for SDU and MDU pit and pipe design (enAble ID 439386), with NBN Pathway Designer and Pit and Pipe Designer training, and has delivered more than 300 NBN designs since 2022. About us

What we design

Single dwelling units (SDU)

Estates, subdivisions and groups of stand-alone lots, including duplexes and triplexes. NBN requires a dedicated lead-in conduit from a pit into each premises, and we design the pits, routes and conduit sizes.

SDU pit and pipe design

Multi dwelling units (MDU)

Buildings and sites with multiple dwellings in one lot, including apartment buildings and sites where shared land will be owned by a body corporate.

MDU pit and pipe design

Why use an NBN trained designer

NBN recommends working with a trained designer so your development is built right the first time and certification moves faster.

See where design fits in the NBN process

  • Designed to NBN's standard

    Pit locations, conduit sizes and routes, and a lead-in conduit to every premises, all prepared to NBN's current pit and conduit standard.

  • Built right the first time

    NBN's training is built around designs that pass review and are installed correctly, which keeps rework off your programme.

  • Two-week turnaround

    Plans turned around within two weeks of receiving complete CAD plans.

  • Australia-wide

    NBN's new developments process is national. Send plans for a development in any state or territory.

Simple per-unit pricing

From $120 per unit, with the rate dropping as your project grows. Your free quote confirms the final price.

Optional add-ons: NBN application concierge, rush turnaround, as-built only, and a fixed-price duplex package.

Full price guide and calculator

SDU or MDU design, price per unit by project size
Units in the projectPrice per unit
1 to 10$120
11 to 25$108
26 to 50$95
51 to 100$82
101 or more$70
